TECHNICAL SHEET RENAULT
Tractor unit RENAULT T 480 T4X2 OPTIFUEL E6 1

RENAULT

Main characteristics

Range T
Model 480 t4x2 optifuel e6
Type of vehicle Tractor
Axles configuration 4x2
GVWR 19 000 kg
Maximum allowable weight 44 000 kg
Max. front weight 7 500 kg
Max. back weight 13 000 kg
Used Renault tractor unit Used Renault Gamme T tractor units
Tractor unit RENAULT T 480 T4X2 OPTIFUEL E6

Measurements Tractor unit RENAULT T 480 T4X2 OPTIFUEL E6

480 T4X2 OPTIFUEL E6
Sleeper cab
Wheel base38

A / Overall length

5,990 m

B / Width

2,518 m

C / Chassis cab width

-

D / Chassis cab width rear under-frame

-

E / Front overhang

1,365 m

F / Wheel base

3,800 m

N / Rear overhang

0,825 m

H1 / Empthy chassis height (front)

0,980 m

H1 / Loaded chassis height (front)

0,922 m

T / Empty cab height

3,926 m

Y / Minimum fifth wheel lead

0,150 m

Y / Max. fifth wheel lead

0,850 m

Y / Standard fifth wheel lead

0,675 m

Turning radius inbetween walls

6,856 m

Masses

Sleeper cab
Wheel base38

Engines DTI 13

NameDTI 13
Engine size12,8 l
Bore × stroke 131 x 158 mm
Administrative power34 cv
Max. power353 kW de 1404 à 1800 tr/min
Maximum torque2400 Nm de 950 tr/min à 1404 tr/min
Oil capacity-
Cooling circuit (with retarder)-
Coolant (without retarder)-
Motor retarder - braking power-
Key
  • : Standard equipment
  • : Equipments in option

Notes :

1 The information and pictures of this technical sheet are given on an indicative basis. All these data may be modified by the manufacturer. For more information, you can directly go to your dealership.
