TECHNICAL SHEET DAF Tractor unit DAF XF FTG 450 (430/480/530) 6x2 1 DAF

Main characteristics

Range XF
Model FTG 450 (430/480/530) 6x2
Type of vehicle Tractor
Axles configuration 6x2
Empty weight -
GVWR 26 000 kg
Maximum allowable weight 44 000 kg
Max. front weight 8 000 kg
Max. back weight 19 000 kg
FTG 450 (430/480/530) 6x2

Measurements Tractor unit DAF XF FTG 450 (430/480/530) 6x2

dimensions
Space CabSuper Space Cab
Model39413941
A / Overall length6,310 m6,510 m6,310 m6,510 m
B / Width2,550 m
C / Chassis cab width-
D / Chassis cab width rear under-frame-
E / Front overhang1,370 m
F / Wheel base3,950 m4,150 m3,950 m4,150 m
H1 / Empthy chassis height (front)0,970 m
H1 / Loaded chassis height (front)0,950 m
N / Rear overhang0,990 m
T / Empty cab height3,530 m
Y / Max. fifth wheel lead -
Y / Minimum fifth wheel lead-
Y / Standard fifth wheel lead-
Turning radius inbetween walls-

Masses

Space CabSuper Space Cab
Model39413941
Total weight8,506 kg8,581 kg8,569 kg8,644 kg
Minimum weight on front axle-
Minimum weight on rear axle-
Chassis cab front axle weight5,234 kg5,256 kg5,296 kg5,319 kg
Chassis cab rear axle weight3,272 kg3,325 kg3,273 kg3,325 kg

Engines

NameXF 430 MX-13XF 450 MX-11XF 480 MX-13XF 530 MX-13
Administrative power----
Bore × stroke----
Coolant (without retarder)----
Cooling circuit (with retarder)----
Engine size----
Motor retarder - braking power----
NameXF 430 MX-13XF 450 MX-11XF 480 MX-13XF 530 MX-13
Oil capacity----
Power315 kW (428 ch)330 kW (449 ch) à 1600 tr/min355 kW (483 ch)390 kW (530 ch)
Torque-2300 Nm à 900- 1125 tr/min--
Key
  • : Standard equipment
  • : Equipments in option

Notes :

1 The information and pictures of this technical sheet are given on an indicative basis. All these data may be modified by the manufacturer. For more information, you can directly go to your dealership.
