TECHNICAL SHEET DAF Tractor unit DAF CF CF 400/440 FT Low Deck 1 DAF

Main characteristics

Range CF
Model CF 400/440 FT Low Deck
Type of vehicle Tractor
Axles configuration 4x2
Empty weight -
GVWR 19 500 kg
Maximum allowable weight -
Max. front weight 7 100 kg
Max. back weight 11 500 kg
CF 400/440 FT Low Deck

Measurements Tractor unit DAF CF CF 400/440 FT Low Deck

dimensions
CourteCouchetteSpace Cab
Model363836383638
A / Overall length5,840 m6,040 m5,840 m6,040 m5,840 m6,040 m
B / Width2,550 m
C / Chassis cab width0,580 m
D / Chassis cab width rear under-frame-
E / Front overhang1,370 m
F / Wheel base3,600 m3,800 m3,600 m3,800 m3,600 m3,800 m
H1 / Empthy chassis height (front)0,830 m
H1 / Loaded chassis height (front)0,830 m
N / Rear overhang0,870 m
T / Empty cab height2,880 m
Y / Max. fifth wheel lead 0,730 m0,770 m0,807 m0,825 m0,807 m0,825 m
Y / Minimum fifth wheel lead0,540 m0,570 m0,154 m0,153 m0,154 m0,153 m
Y / Standard fifth wheel lead-
Turning radius inbetween walls7,160 m7,420 m6,656 m6,856 m6,656 m6,856 m

Masses

CourteCouchetteSpace Cab
Model363836383638
Total weight6 765 kg6 695 kg6 705 kg6 755 kg6 765 kg
Minimum weight on front axle-
Minimum weight on rear axle-
Chassis cab front axle weight4 670 kg
Chassis cab rear axle weight1 955 kg1 965 kg1 955 kg1 965 kg1 955 kg

Engines

NameMX-11
Administrative power-
Bore × stroke131 x 158 mm
Coolant (without retarder)-
Cooling circuit (with retarder)-
Engine size10,8 l
Max. power291 kW (396 CV) de 1404 à 1800 tr/min
Maximum torque1900 Nm de 1000 tr/min à 1450 tr/min
Motor retarder - braking power-
NameMX-11
Oil capacity-
Key
  • : Standard equipment
  • : Equipments in option

Notes :

1 The information and pictures of this technical sheet are given on an indicative basis. All these data may be modified by the manufacturer. For more information, you can directly go to your dealership.
