TECHNICAL SHEET Volvo
Tractor unit Volvo FH D 13 64 HA Tracteur Suspension Pneumatique 1
Main characteristics
Range | FH |
Model | D 13 64 HA Tracteur Suspension Pneumatique |
Type of vehicle | Tractor |
Axles configuration | 6x4 |
Empty weight | - |
GVWR | 26 000 kg |
Maximum allowable weight | 44 000 kg |
Max. front weight | 7 100 kg |
Max. back weight | 21 000 kg |

Measurements Tractor unit Volvo FH D 13 64 HA Tracteur Suspension Pneumatique

CAB-HSLP | |||||
---|---|---|---|---|---|
Model | 30 | 32 | 34 | 37 | 39 |
A / Overall length | 6,540 m | 6,740 m | 6,940 m | 7,140 m | 7,440 m |
B / Width | 2,495 m | ||||
C / Chassis cab width | - | ||||
D / Chassis cab width rear under-frame | - | ||||
E / Front overhang | 1,365 m | ||||
F / Wheel base | 3,000 m | 3,200 m | 3,400 m | 3,700 m | 3,900 m |
H1 / Empthy chassis height (front) | 1,064 m | ||||
H1 / Loaded chassis height (front) | - | ||||
N / Rear overhang | 0,805 m | ||||
T / Empty cab height | 3,498 m | ||||
Y / Max. fifth wheel lead | - | ||||
Y / Minimum fifth wheel lead | - | ||||
Y / Standard fifth wheel lead | - | ||||
Turning radius inbetween walls | 6,650 m | 6,950 m | 7,250 m | 7,550 m | 8,050 m |
Masses
CAB-HSLP | |||||
---|---|---|---|---|---|
Model | 30 | 32 | 34 | 37 | 39 |
Total weight | 8 810 kg | 8 830 kg | 8 855 kg | 8 870 kg | 8 895 kg |
Minimum weight on front axle | - | ||||
Minimum weight on rear axle | - | ||||
Chassis cab front axle weight | 5 080 kg | 5 105 kg | 5 130 kg | 5 145 kg | 5 175 kg |
Chassis cab rear axle weight | 3 730 kg | 3 725 kg | 3 725 kg | 3 725 kg | 3 720 kg |
Engines
Name | D13K420 | D13K460 | D13K500 | D13K540 |
Administrative power | - | - | - | - |
Bore × stroke | 131 x 158 mm | 131 x 158 mm | 131 x 158 mm | 131 x 158 mm |
Catalyst and injection | - | - | - | - |
Coolant (without retarder) | - | - | - | - |
Cooling circuit (with retarder) | - | - | - | - |
Engine size | 12,8 l | 12,8 l | 12,8 l | 12,8 l |
Max. power | 309 kW (420 ch) de 1400 à 1800 tr/min | 338 kW (460 ch) de 1400 à 1800 tr/min | 368 kW (500 ch) de 1400 à 1800 tr/min | 397 kW (540 ch) de 1450 à 1800 tr/min |
Maximum torque | 2100 Nm à 860-1400 tr/min | 2300 Nm à 900-1400 tr/min | 2500 Nm à 1000-1400 tr/min | 2600 Nm à 1000-1400 tr/min |
Motor retarder - braking power | 375 kW | 375 kW | 375 kW | 375 kW |
Name | D13K420 | D13K460 | D13K500 | D13K540 |
Oil capacity | - | - | - | - |
