TECHNICAL SHEET MAN Tractor unit MAN TGX 33.520 (560) 6x4 BBS Euro 6 1 MAN

Main characteristics

Range TGX
Model 33.520 (560) 6x4 BBS Euro 6
Type of vehicle Tractor
Axles configuration 6x4
Empty weight -
GVWR 26 T / 33 T
Maximum allowable weight 40 T / 44 T / 50 T / 60 T
Max. front weight 8 T
Max. back weight 21 T
33.520 (560) 6x4 BBS Euro 6

Measurements Tractor unit MAN TGX 33.520 (560) 6x4 BBS Euro 6

dimensions
XLXLX (Mi-haute)XXL (surélevée)
Model333639333639333639
A / Overall length6,875 m7,175 m7,475 m6,875 m7,175 m7,475 m6,875 m7,175 m7,475 m
B / Width2,472 m
C / Chassis cab width-
D / Chassis cab width rear under-frame-
E / Front overhang1,475 m
F / Wheel base3,300 m3,600 m3,900 m3,300 m3,600 m3,900 m4,000 m4,300 m4,600 m
H1 / Empthy chassis height (front)-
H1 / Loaded chassis height (front)-
N / Rear overhang0,700 m
T / Empty cab height3,280 m
Y / Max. fifth wheel lead 0,519 m0,556 m0,593 m0,519 m0,556 m0,593 m0,497 m0,533 m0,569 m
Y / Minimum fifth wheel lead-
Y / Standard fifth wheel lead0,375 m0,425 m0,425 m0,375 m0,425 m0,425 m0,375 m0,425 m0,425 m
Turning radius inbetween walls8,450 m8,900 m9,300 m8,450 m8,900 m9,300 m8,450 m8,900 m9,300 m

Masses

XLXLX (Mi-haute)XXL (surélevée)
Model333639333639333639
Total weight10 030 kg10 040 kg10 090 kg10 050 kg10 060 kg10 110 kg10 075 kg10 085 kg10 135 kg
Minimum weight on front axle4 500 kg
Minimum weight on rear axle3 600 kg
Chassis cab front axle weight5 565 kg5 570 kg5 575 kg5 585 kg5 590 kg5 595 kg5 610 kg5 615 kg5 620 kg
Chassis cab rear axle weight4 465 kg4 470 kg4 515 kg4 465 kg4 470 kg4 515 kg4 465 kg4 470 kg4 515 kg

Engines

NameMAN D3876LF01 « Common Rail »MAN D3876LF02 « Common Rail »
Administrative power41 cv41 cv
Bore × stroke138 x 170 mm138 x 170 mm
Catalyst and injectionCatalyseur SCR et injection AdBlueCatalyseur SCR et injection AdBlue
Coolant (without retarder)--
Cooling circuit (with retarder)--
Engine size15,256 L15,256 L
Max. power412 kW (560 ch) à 1800 tr/min383 kW (520 ch) à 1800 tr/min
Maximum torque2700 Nm de 930 à 1400 tr/min2500 Nm de 930 à 1350 tr/min
Motor retarder - braking power--
NameMAN D3876LF01 « Common Rail »MAN D3876LF02 « Common Rail »
Oil capacity--
Key
  • : Standard equipment
  • : Equipments in option

Notes :

1 The information and pictures of this technical sheet are given on an indicative basis. All these data may be modified by the manufacturer. For more information, you can directly go to your dealership.
