TECHNICAL SHEET IVECO
Tractor unit IVECO Stralis AD 440 S 42/46/48 TP 1

IVECO

Main characteristics

Range Stralis
Model Ad 440 s 42/46/48 tp
Type of vehicle Tractor
Axles configuration 4x2
GVWR 19 000 kg
Maximum allowable weight 44 000 kg
Max. front weight 8 000 kg
Max. back weight 13 000 kg
Used Iveco tractor unit Used Iveco Stralis tractor units
Tractor unit IVECO Stralis AD 440 S 42/46/48 TP

Measurements Tractor unit IVECO Stralis AD 440 S 42/46/48 TP

AD 440 S 42/46/48 TP
Hi-Street
Wheel base3638

A / Overall length

6,068 m6,248 m

B / Width

2,550 m

C / Chassis cab width

-

D / Chassis cab width rear under-frame

-

E / Front overhang

1,410 m

F / Wheel base

3,610 m3,790 m

N / Rear overhang

1,048 m

H1 / Empthy chassis height (front)

0,950 m

H1 / Loaded chassis height (front)

0,920 m

T / Empty cab height

2,963 m

Y / Minimum fifth wheel lead

0,270 m0,290 m

Y / Max. fifth wheel lead

0,880 m0,920 m

Y / Standard fifth wheel lead

-

Turning radius inbetween walls

7,100 m7,300 m

Masses

Hi-Street
Wheel base3638

Engines FPT Cursor 11 / CNG E6-F3GFE611D FPT Cursor 11 / CNG E6-F3GFE611B FPT Cursor 11 / CNG E6-F3GFE611A

NameCNG E6-F3GFE611D CNG E6-F3GFE611B CNG E6-F3GFE611A
Engine size11,118 L11,118 L11,118 L
Bore × stroke 128 x 144 mm128 x 144 mm128 x 144 mm
Administrative power30 cv30 cv30 cv
Max. power309 kW (420 ch) de 1550 à 1900 tr/min338 kW (460 ch) de 1575 à 1900 tr/min353 kW (480 ch) de 1550 à 1900 tr/min
Maximum torque1900 Nm de 1050 à 1550 tr/min2150 Nm de 1050 à 1550 tr/min2250 Nm de 1050 à 1550 tr/min
Oil capacity26 L26 L26 L
Cooling circuit---
Motor retarder - braking power---
Key
  • : Standard equipment
  • : Equipments in option

Notes :

1 The information and pictures of this technical sheet are given on an indicative basis. All these data may be modified by the manufacturer. For more information, you can directly go to your dealership.
